WMD SKORPION Waverform Reanimator


Skorpion is an 8-stage analog wavefolder that allows you to precisely mangle simple waveforms into complex shapes with a fun, hands on fader interface.  Taking the concept many steps further, internal modulation sources allow for macro animation of multiple parameters simultaneously, creating rich, evolving harmonic movement never heard before in hardware.

Features:

  • Analog Vector Core Wavefolder
  • 8 Stage Equivalent
  • 16 reversal points (8 positive and 8 negative)
  • Macro Animation over Fold, Slope, Shape, Shift, and all eight Thresholds.
  • Single Macro Gate Input to control Animation
  • 12 internal LFOs, 5 internal envelopes
  • Mono to Stereo Operation
  • Proprietary vector based delay core
  • Wet/Dry/Wide Control
  • Low Frequencies stay Mid. Wide forces high frequencies to sides of stereo field
  • 1V/Oct Tracking
  • Easy to learn single sub-layer for advanced controls
  • Hard/Soft sync
  • Shape control with eight feedback sources
  • Tons of utility outputs and CV inputs for endless experimentation
  • Black or Silver Panel Option

999€

Stromverbrauch: 20mA auf +12V und 20mA auf -12V

Tiefe: 40mm




20 HP
